Alumina Boats
Alumina ceramic boat is a high-temperature resistant ceramic product with a unique manufacturing process and a wide range of uses. It can withstand high temperatures of 1600 degrees Celsius and has excellent corrosion resistance and mechanical properties. The capacity of ceramic boats ranges from 0.2ml to 36ml and is mainly used in testing laboratories and various industrial analyses. Edgetech provides alumina boats with and without holes..
Performance for Typical Alumina Ceramics
| Item | Unit | Al2O3 |
| Physical Property | ||
| Color | Ivory | |
| Density | g/cm3 | 3.7-3.9 |
| Purity | % | 95~99.8 |
| Gas Permeability | 0 | |
| Water Absorption | 0% | |
| Mechanical Properties | ||
| Vickers Hardness | GPa | 12.3-17.2 |
| Flexural Strength | MPa | 300-380 |
| Compressive Strength (HV0.5) | MPa | 2000-2350 |
| Elastic modulus | GPa | 270-380 |
| Fracture Toughness | MPam1/2 | 3.5-4 |
| Thermal Properties | ||
| The Max Working Temperature | ℃ | 1650 |
| Thermal Conductivity at room temperature | W/(m·K) | 20-32 |
| Coefficient of Thermal Expansion | 10-6/℃ | 6.5-7.2 |
| Thermal Shock Resistance | △T℃ | 200 |
| Electrical Properties | ||
| Dielectric Strength | KV/mm | 10-15 |
| Dielectric Constant | 9-10 | |
| Dielectric Loss Angle(1MHz) | 0.0002-0.0003 | |
| Volume Resistivity | Ω·cm | >1014 |
The above chart just demonstrates the typical properties of common alumina ceramic we use to produce our alumina parts. Please notice that the properties of customized alumina parts vary due to different processing. Edgetech Industries, Advanced Ceramics Division provides alumina products according to your specified instructions, or do the best to meet requirements.
-
Boron Nitride Tube -
BN Tubes
Alumina Boats Application
It is often used in high-temperature smelting, chemical reactions, laboratory research, and other fields. Due to its high-temperature resistance and chemical stability, alumina boats can withstand extreme working environments and ensure safe and effective operation. At the same time, alumina boats are also widely used in the preparation of high-purity materials, the production of special alloys, etc., providing important technical support for various industries.
Packing of alumina ceramic tubes
As a ceramic material, the Alumina Boat is quite fragile in a lot of cases. Our Alumina Ceramics are carefully handled to minimize damage during storage and transportation. Suitable outer boxes and inner cushioning materials are used, and vacuum packing is also engaged for some of the parts.
