Phosphors
We provide LED phosphor, Trichromatic Phosphors, Mixed Trichromatic Phosphors with different wavelength and applications.
Our LED Phosphor Listing
| Series | Model |
Color coordinates (460nm excitation) |
Peak WL λp (nm) | FWHM (nm) | Particle size D50(μm) | Best WL Ex (nm) | Feature | Inquiry | ||
| x±0.002 | y±0.002 | |||||||||
| YAG Phosphor | L-552 | 0.420 | 0.552 | 547±2 | 115±1 | 8±1 | 445-460 | Low power, cool white | Inquiry | |
| L-548 | 0.425 | 0.548 | 550±2 | 115±1 | 8±1 | 450-460 | Low power, white | Inquiry | ||
| L-538 | 0.440 | 0.538 | 556±2 | 118±1 | 8±1 | 450-465 | Inquiry | |||
| L-534 | 0.447 | 0.534 | 560±2 | 118±1 | 8±1 | 450-465 | Inquiry | |||
| L-580S | 0.494 | 0.496 | 575±2 | 131±1 | 8±1 | 450-465 | Low power, warm white | Inquiry | ||
| M-552 | 0.421 | 0.552 | 547±2 | 112±1 | 12±1 | 445-460 | Medium Power, white | Inquiry | ||
| M-548 | 0.429 | 0.548 | 550±2 | 113±1 | 12±1 | 450-460 | Inquiry | |||
| M-538 | 0.439 | 0.538 | 553±2 | 116±1 | 12±1 | 450-465 | Inquiry | |||
| M-534 | 0.447 | 0.534 | 560±2 | 118±1 | 12±1 | 450-465 | Inquiry | |||
| H-552L | 0.421 | 0.552 | 545±2 | 112±1 | 15±1 | 445-460 | High power, cool white | Inquiry | ||
| H-548L | 0.428 | 0.548 | 550±2 | 113±1 | 15±1 | 450-460 | High power, white | Inquiry | ||
| H-538 | 0.443 | 0.538 | 556±2 | 114±1 | 15±1 | 450-465 | Inquiry | |||
| H-534 | 0.447 | 0.534 | 560±2 | 115±1 | 15±1 | 450-465 | Inquiry | |||
| GaYAG Phosphor | YG-525L | 0.345 | 0.571 | 525±2 | 105±1 | 15±1 | 445-460 | High color | Inquiry | |
| YG-530L | 0.365 | 0.570 | 530±2 | 106±1 | 15±1 | 445-460 | Inquiry | |||
| YG-533L | 0.371 | 0.570 | 533±2 | 106±1 | 15±1 | 445-460 | Inquiry | |||
| YG-535L | 0.380 | 0.569 | 535±2 | 107±1 | 15±1 | 445-460 | Inquiry | |||
| YG-537L | 0.386 | 0.568 | 537±2 | 107±1 | 15±1 | 445-460 | Inquiry | |||
| YG-540L | 0.395 | 0.563 | 538±2 | 107±1 | 15±1 | 445-460 | Inquiry | |||
| LuAG Phosphor | LAG-520 | 0.332 | 0.577 | 518±2 | 103±1 | 15±1 | 425-475 | Backlight, high color | Inquiry | |
| LAG-535 | 0.356 | 0.575 | 536±2 | 105±1 | 15±1 | 425-475 | Inquiry | |||
| LAG-537 | 0.363 | 0.575 | 537±2 | 105±1 | 15±1 | 425-475 | Inquiry | |||
| LAG-540 | 0.370 | 0.573 | 538±2 | 105±1 | 15±1 | 425-475 | Inquiry | |||
| Silicates Phosphor | S-505 | 0.188 | 0.600 | 510±3 | 60±1 | 16±1 | 200-500 | Backlight, high color | Inquiry | |
| S-520 | 0.260 | 0.637 | 520±3 | 66±1 | 16±1 | 200-500 | Inquiry | |||
| S-525 | 0.277 | 0.638 | 525±3 | 64±1 | 16±1 | 200-500 | Inquiry | |||
| S-600 | 0.580 | 0.418 | 599±3 | 78±1 | 16±1 | 200-500 | Inquiry | |||
| Nitride Phosphor | R-615BHG | 0.621 | 0.378 | 615±1 | 75±2 | 12±1 | 380-480 | Warm white, high color | Inquiry | |
| R-625BHG | 0.640 | 0.359 | 623±1 | 75±2 | 12±1 | 380-480 | Inquiry | |||
| R-630BHG2 | 0.646 | 0.353 | 625±1 | 77±2 | 12±1 | 380-480 | Inquiry | |||
| R-630BHG3A | 0.644 | 0.354 | 625±1 | 77±2 | 12±1 | 380-480 | Inquiry | |||
| R-635BHG | 0.652 | 0.348 | 632±1 | 80±2 | 12±1 | 380-480 | Inquiry | |||
| R-650BHD | 0.650 | 0.345 | 645±1 | 89±2 | 13±1 | 380-480 | Inquiry | |||
| R-650BHE | 0.665 | 0.330 | 650±1 | 90±2 | 11±1 | 380-480 | Inquiry | |||
| R-660BHG | 0.665 | 0.330 | 652±1 | 90±2 | 13±1 | 380-480 | Inquiry | |||
| R-660BHC | 0.678 | 0.317 | 658±1 | 89±2 | 10±1 | 380-480 | Inquiry | |||
| R-660N | 0.674 | 0.321 | 669±1 | 121±2 | 8±1 | 380-480 | Inquiry | |||
| R-660 |
0.670 ±0.003 |
0.326 ±0.003 |
665±1 | 116±2 | 5±1 | 380-480 | Inquiry | |||
| Oxynitride Phosphor | NO-490 |
0.085 ±0.005 |
0.466 ±0.005 |
495±2 | 31±2 | 15±1 | 380-480 | Full-spectrum, high color | Inquiry | |
Our Special Monochromatic Phosphor Listing
| Product | Type |
Chemical composition |
Emission peak wavelength (nm) | Application | Inquiry |
| Blue Trichromatic Phosphor | T42-015 | Sr2P2O7:Eu | 420±1 | Used for biological viewing, aquarium or neon. | Inquiry |
| T46-015 | Sr2P2O7:Sn | 460±10 | For color lights, neon lights, night lights or fluorescent lights to change color and plant growth light source. | Inquiry | |
| T48-028 |
2SrO·0.84P2O5 ·0.16B2O3:Eu |
480±3 | Improve display performance. | Inquiry | |
| T49-028 | Sr4Al14O25:Eu | 490±3 | Improve display performance. | Inquiry | |
| T49-015 | Ba2P2O7:Ti | 490±2 | Improve display performance. | Inquiry | |
| Green Trichromatic Phosphor | T51-528 | (BaEu)MgAl10O17:Mn | 515±1 | Used for neon lights, night lights or special color requirements for lights. | Inquiry |
| T52-539 | Zn2SiO4:Mn | 525±2 | For color lights, neon lights, night lights。 | Inquiry | |
| Red Trichromatic Phosphor | T62-511 | (CeGdTb)(MgMn)B5O10 | 625±2 | For the change of light and plant growth light source. | Inquiry |
| T62-529 | (CeGd)(MgMn)B5O10 | 625±2 | For the change of light and plant growth light source. | Inquiry | |
| T66-015 |
3.5MgO·0.05Mg F2·GeO2:Mn |
660±1 | For the change of light and plant growth light source. | Inquiry | |
| Ultraviolet Phosphor | T30-528 | SrBaMgAl11O19:Ce | 305～370 | For anti-counterfeiting money, light of the lamp - copy, lure lights, health, such as UV lamps. | Inquiry |
| T31-528 | Inquiry | ||||
| T32-528 | Inquiry | ||||
| T33-528 | Inquiry | ||||
| T34-528 | Inquiry | ||||
| T31-215 | (Y,Gd,Ce)MgB5O10 | 312±2 | Inquiry | ||
| T31-538 | LaPO4:Ce | 315 | Inquiry | ||
| T35-538 | YPO4:Ce | 355 | Inquiry | ||
| T37-039 | SrB4O7:Eu | 368 | Inquiry | ||
| T39-018 | (SrMg)2P2O7:Eu | 390 | Used for biological viewing, aquarium or lure light. | Inquiry |
Our Regular Monochromatic Phosphor Listing
| Product | Type |
Chemical composition |
Emission peak wavelength (nm) | Application | Inquiry |
| Rare Earth Red Phosphor | KR | Y2O3:Eu | 611±1 | Used for the CFL, straight lamp, ring lamp, CCFL, fluorescent lamp with shade, electrodeless lamps and other fluorescent lamps. | Inquiry |
| Rare Earth Phosphate Green Phosphor | KG | LaPO4:Ce,Tb | 544±1 | Used for the CFL, straight lamp, ring lamp, CCFL, fluorescent lamp with shade, electrodeless lamps and other fluorescent lamps. | Inquiry |
| Rare Earth Aluminate Green Phosphor | KG | CeMgAl11O19:Tb | 544±1 | Used for the CFL, straight lamp, ring lamp, CCFL, fluorescent lamp with shade, electrodeless lamps and other fluorescent lamps. | Inquiry |
| Rare Earth Double-peak Blue Phosphor | KC | BaMgAl10O17:Eu,Mn | 454±1 | Used for the CFL, straight lamp, ring lamp, CCFL, fluorescent lamp with shade, electrodeless lamps and other fluorescent lamps. (Secondary peak513±1nm) | Inquiry |
| Rare Earth Single-peak Blue Phosphor | KB | BaMgAl10O17:Eu | 450±1 | Used for the CFL, straight lamp, ring lamp, CCFL, fluorescent lamp with shade, electrodeless lamps and other fluorescent lamps. | Inquiry |
Our Mixed Phosphor Listing
| Product | Color temperature | Emission peak wavelength (nm) | Application | Inquiry |
| Rare Earth Mixed Phosphor (including aluminate series and phosphate series) | 2700K～3000K | 611±1 | Used for the CFL, straight lamp, ring lamp, CCFL, fluorescent lamp with shade, electrodeless lamps, etc.(Other color temperature can be customized) | Inquiry |
| 3500K～6500K | 544±1 | Inquiry | ||
| Full Spectrum Phosphor | 4000K～6000K Full spectrum | 480±2 | Used for the CFL, straight lamp, other full spectrum lamp.(Per requirements) | Inquiry |
| 4000K～6500K High Color | 544±1 | Inquiry | ||
| Cold Cathode Phosphor | 2700K～3000K | 611±1 | Used for CCFLCold cathode backlight. (Other color temperature can be customized) | Inquiry |
| 3500K～6500K | 544±1 | Inquiry | ||
| Special Phosphor | —— | —— | Used for plant growth lights, mosquito lamp, mosquito lamp, health lights, UV lamps and so on. (Per requirements) | Inquiry |
| Neon Lights Phosphor | Pink, purple, yellow, white, ultra-white | —— | Used for color lights, neon lights, night lights. (Other color temperature can be customized) | Inquiry |
Products
-
Red Phosphor
Edgetech Industries LLC provides high quality red phosphor, which is also named as red lamp phosphor, Trichromatic phosphors, Y2O3: Eu, Red trichromatic phosphor.
-
Blue Phosphor
Edgetech Industries LLC provides high quality aluminate blue phosphor, which is also named as BaMgAl10O17: Eu, BAM, aluminate blue phosphor, rare earth single-peak aluminate blue phosphor.
